Custom ERW Pipe Mill For Carbon / GI Steel Tube 4.0-10.0mm Pipe Thickness

Name: Custom ERW Pipe Mill For Carbon GI Steel Tube 40100mm Pipe Thickness
Brand: Tengtian
Price: 100000 USD

Custom ERW Pipe Mill For Carbon / GI Steel Tube 4.0-10.0mm Pipe Thickness Manufactures

Brand Name : Tengtian

Model Number : HG76

Certification : CE, ISO9001, BV

Place of Origin : HEBEI,CHINA

MOQ : 1 set

Price : $100000 to $1 million

Payment Terms : L/C, T/T, Western Union

Supply Ability : 50 set per year

Delivery Time : 3 months

Packaging Details : Export waterproof and Seaworthy packing.

product name : Custom ERW Pipe Mill For Carbon / GI Steel Tube 4.0-10.0mm Pipe Thickness

product speed : Max 50m/min

Pipe Diameter : 21 - 63mm

material : carbon steel,stainless steel,low alloy steel

Cutting Saw : Friction Saw Cutting

worm gearing : Max.80m/min

pipe thickness : 4.0-10.0mm

keywords : Custom ERW Pipe Mill

Contact Now

ERW high frequency welding carbon steel water supply pipe production mill

The application of advanced aperture technology, PLC automatic control system and Digital speed regulating unit ensure that the production line works reliably and operates and maintains easily.

Introduction

This equipment is specially used for producing Carbon High Frequency Welded Pipe Mill. It made by refined materials in high precision and equipped with fixed length cutting saw. The main machine includes forming, welding, sizing and straightening device. The composition of equipment is from decoiler to fixed length-cutting saw. Rolling speed can be adjusted correspondingly within suitable range of pipe diameter and wall thickness.

Process of the Production Line

Raw material (strip steel roll) – Material feeding – End cutting and butt welding (hand welding) – Strip storage cage – Material feeding and forming – High frequency welding – Removing outer burr – Cooling water jacket – Fix the diameter and straightening – Cut off with flying saw – Material unloading (Manually stow and bind up) – Inspection – Storehouse

Technical parameter

High frequency welded pipe mil

Description	WB12 tube mill line	WB25 tube mill line	WB32 tube mill line	WB50 tube mill line
Diameter of welded tubes	Φ7-25mm	Φ8-32mm	Φ13-50mm	Φ20-60mm
Wall thickness of welded tubes	0.3-1.0mm	0.4-1.5mm	0.6-1.8mm	0.8-2.7mm
Speed of tube welding	90M/min	90M/min	90M/min	70M/min
Power of major motor	22KW	37KW	55KW	75KW
Power of high frequency welder	60KW	60KW	100KW	100KW

ERW Tube Mill Other Model

Model	Diameter Range	Pipe Thickness	Line Speed(m/min)
HG20	8-25.4MM	0.3-1.2MM	120
HG32	10-32MM	1.4-1.5MM	120
HG50	16-76MM	0.7-2.5MM	30-120
HG76	25-76MM	1-4MM	30-100
HG89	32-89MM	1-4.5MM	30-80
HG114	45-114MM	1.5-5.0MM	30-60
HG165	60-165MM	3-7MM	30-50
HG219	114-219MM	4-8MM	20-40
HG273	114-273MM	4-10MM	15-30
HG325	165-325MM	4-10MM	10-30
HG426	165-426MM	4-12.7MM	8-25
HG508	219-508MM	4-16MM	8-20

Custom ERW Pipe Mill For Carbon / GI Steel Tube 4.0-10.0mm Pipe Thickness

Our Services

1.) We will send the engineer for the installation and training your workers how to operate this machine in correct way.

2.) Warranty Team

One year quality guarantee, life guarantee repair. Within quality guarantee period, except for failures caused by human error, repair parts will be provided for free. After the quality guarantee period, only charge the cost of the spare parts.

3.) We supply the pre-sell and after-sell service.

pre-sell service: workshop design, and production output design

after-sell service: installation and training, and the skilled engineer for working.

4.) We can also sent the engineer working for you serval months or 1 year. The engineer will help you to improve the output, reduce the waste and decrease the cost.

5.) We supply the pre-sell service-Design for whole project for stainless steel pipe making/ carbon steel pipe making.

6.) We will be responsible for the loading and shipping

Product Tags:

erw tube mill

slitting line machine

Custom ERW Pipe Mill For Carbon / GI Steel Tube 4.0-10.0mm Pipe Thickness Images
