Automated Intelligent 100mm Round Pipe Making Machine Automatic Tube Mill

Name: Automated Intelligent 100mm Round Pipe Making Machine Automatic Tube Mill
Brand: TENGTIAN
Price: 100000 USD

Automated Intelligent 100mm Round Pipe Making Machine Automatic Tube Mill Manufactures

Brand Name : TENGTIAN

Model Number : 127

Certification : CE ISO9000 BV

Place of Origin : China

MOQ : 1 set

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 5 set/year

Delivery Time : 100 working days

Packaging Details : standard export package

Mill Name : Automated Intelligent 100mm Round Pipe Making Machine Automatic Tube Mill

Feature : Professional Customed

Other pipe : round pipe and square pipe

Max size : 50 - 100mm

Thickness : 1 . 5 - 4 . 0 mm

Length : 4 - 12 m

Rollers : include

Warranty : one year

Key words : Round Pipe Making Machine / Steel Pipe Forming Machine

Price : $100000 to $1 million

Contact Now

Automated Intelligent 100mm Round Pipe Making Machine Automatic Tube Mill

1.Intelligent Industrial Round Pipe Making Machine / Steel Pipe Forming Machine General Introduction

Automated Intelligent 100mm Round Pipe Making Machine Automatic Tube Mill is mainly used to produce round pipes of 60 to127 mm, wall thickness of 1.5 to 4.5 mm and square pipes, and can also produce square pipes of 50×50-100×100mm and thickness of 1.5 to 4.0mm under the corresponding raw material conditions tube. On the basis of digesting and absorbing similar equipment at home and abroad, each single machine of this production line is innovatively designed in combination with my country's national conditions. The operation and maintenance are convenient, the design level and manufacturing quality are in the leading position in the country, and the structure and precision have reached the level of the units introduced in recent years. This unit has high processing quality and assembly accuracy, and adopts a reasonable roll pass, which can produce electric welded steel pipes with relatively high precision.

2. Intelligent Industrial Round Pipe Making Machine / Steel Pipe Forming Machine Product Process:

Coil Loading → Uncoiler → Shear and Welding → Horizontal Accumulator → Forming and Sizing → Cutting saw → Straight machine → Packing → Storage

3.Intelligent Industrial Round Pipe Making Machine / Steel Pipe Forming Machine Main Parameters and Specifications:

⑴ Material Specifications:

Material	low carbon steel galvanize and crabon steel tube
Mechanical properties	σ_b≤520Mpa,σ_s≤365MPa
strip width	200 - 400 mm
strip thickness	1 . 5 - 4 . 0 mm
I.D of Coils	Φ 508 - 610 mm
O.D of Coils	φ 2000 mm
Coil Weight	≤ 10T

⑵ Welded Pipe Specification

Square Pipe Diameter	Φ 50 ～ φ 100 mm
pipe thickness	1 . 5 - 4 . 0 mm
Finish pipe length	4 - 12 m
Cut length accuracy	± 3 mm
Forming speed	15 - 60 m/min

4. Exhibition Pic
